Gorilla Playsets Chateau - Decking and Major Component Assembly; STEP 7-10: INSTALLING DECK BOARDS AND SPACERS

STEP 7: BOTTOM PANEL BOARDS
1: PLACE THE 2 X 4 X 47-1/2" BOTTOM PANEL BOARD ON TOP OF THE 2 X 6 PANEL BOARD WITH OFFSET HOLES UP
AND FASTEN TO THE CORNER POSTS WITH 5/16 X 3-1/2" LAG SCREWS WITH 5/16" WASHERS.
2: PLACE THE 2 X 4 X 14" BOTTOM PANEL BOARD ON TOP OF THE 2 X 6 PANEL BOARD, AND FASTEN TO THE CORNER
POSTS WITH 5/16 X 3-1/2" LAG SCREWS WITH 5/16" WASHERS.
COUNTER-SUNK HOLES
5/16" WASHER
ON CENTER
2 X 4 X 14"
BOTTOM PANEL BOARD
5/16 X 3-1/2"
LAG SCREW
BOTTOM PANEL BOARD
5/16" WASHER
OFFSET HOLES UP
2 X 4 X 47-1/2" 5/16 X 3-1/2"
LAG SCREW
