STEP 9: CENTER DECK SUPPORT
1: FIND THE 2 X 4 X 70" CENTER DECK SUPPORT WITHOUT HOLES.
2: FROM THE UNDERSIDE OF THE DECK SPACERS THAT WERE PREVIOUSLY INSTALLED, PLACE THE CENTER DECK
SUPPORT AT THE CENTER OF THE DECK SPACERS (USE THE HOLE ON CENTER AS A GUIDE) AND MAKE A MARK ON
THE OUTSIDE OF THE FORT TO REPRESENT A CENTER LINE.
3: USE 2" WOOD SCREWS TO ATTACH THE DECK SPACERS TO THE CENTER DECK SUPPORT.
4: CENTER THE 2 X 4 X 70" CENTER DECK SUPPORT ON THESE MARKS AND PUSH THE CENTER DECK SUPPORT FLUSH
TO THE BOTTOM SIDE OF THE DECK BOARDS.
5: USING TWO 2-1/2" WOOD SCREWS, INSTALL THE 2 X 4 X 70" CENTER DECK SUPPORT THROUGH THE OUTSIDE OF
THE 2 X 6, AND INTO THE END OF THE CENTER DECK SUPPORT. REPEAT THIS STEP ON THE OPPOSITE END OF THE
FORT.
USE 2-1/2" WOOD SCREWS IN THESE LOCATIONS
2" WOOD SCREW
2 X 4 X 70"
CENTER DECK SUPPORT
