STEP 43: MOUNTING THE TELESCOPE
1: WITH THE 1-1/4" WOOD SCREWS PROVIDED IN THE TELESCOPE BAG, FASTEN ONE OF THE SQUARE
TELESCOPE BRACKETS TO THE FRONT TOP PANEL BOARD, BETWEEN THE TWO PANEL SLATS.
2: PLACE THE TELESCOPE STAND AND TELESCOPE INTO THE SLOT OF THE TELESCOPE BRACKET.
3: FASTEN THE REMAINING TELESCOPE BRACKET TO THE OPPOSITE SIDE THAT THE FIRST TELESCOPE BRACKET
WAS INSTALLED ON WITH 1-1/4" WOOD SCREWS.
TELESCOPE STAND
1-1/4" WOOD SCREW
TELESCOPE BRACKET
TELESCOPE
