Gorilla Playsets Chateau - STEP 19-27: ROOF, SUNBURST, AND SWING BEAM INSTALLATION

2" WOOD SCREW
STEP 19: ROOF SUPPORTS
1: WITH OFFSET HOLES DOWN, ATTACH THE 2 X 4 X 51" ROOF SUPPORTS TO THE FORT WITH 5/16 X 4-1/2" HEX
BOLTS. THE ROOF SUPPORTS SHOULD MEET IN THE MIDDLE TO FORM A RIGHT ANGLE.
2: CONNECT THE ENDS WITH A 2" WOOD SCREW.
RIGHT SIDE
ROOF SUPPORT
5/16" WASHER
2 X 4 X 51"
ROOF SUPPORT
LEFT SIDE
2 X 4 X 51"
5/16 X 4-1/2"
HEX BOLT
