Gorilla Treasure Trove II User Manual

#14 X 1-1/4"
REPEAT FOR OTHER SIDE.
AND 1/4" WASHERS.
PAN HEAD SCREWS
DETAIL A
BOARD WITH
THEN FOLD
THIS TAB UNDER
THE TARP BOARD
AND SECURE IT TO
THE BOTTOM
SIDE OF THE TARP
FASTEN OUTSIDE GROMMETS
FIRST TO THE SIDE OF THE TARP
BOARD ON
EACH SIDE WITH #14 X 1-1/4"
PAN HEAD SCREWS AND
1/4" WASHERS.
REPEAT FOR OTHER SIDE.
TARP
A
1: PLACE THE TARP (LOWER LEVEL) ACROSS THE TARP BOARDS (LOWER LEVEL) WITH THE HEMS ON THE INSIDE.
(NOTE IF YOU WISH YOU MAY PREDRILL HOLES FOR THE PAN HEAD SCREW WITH A 1/8" DRILL BIT.)
2: FASTEN THE OUTSIDE CORNERS OF THE TARP TO THE SIDE OF THE TARP BOARD FIRST. ATTACH THE GROMMETS IN
THE TARP TO THE TARP BOARD WITH #14 X 1-1/4" PAN HEAD SCREWS WITH 1/4" WASHERS. REPEAT FOR OTHER SIDE.
STEP 55: TARP (LOWER LEVEL)
HOLES FOR THE PAN HEAD SCREWS WITH A 1/8" DRILL BIT.)
1-1/4" PAN HEAD SCREWS WITH 1/4" WASHERS. REPEAT FOR OTHER SIDE. ( NOTE IF YOU WISH YOU MAY PREDRILL
3: NOW FOLD THE FLAP UNDER THE TARP BOARD AND FASTEN THE GROMMETS UNDER THE TARP BOARD WITH #14 X
NOTE: IF YOU WISH
YOU MAY DRILL
1/8" PILOT HOLES IN THE
TARP BOARD FOR THE
PAN HEAD SCREWS.
100
