1: PLACE THE BRIDGE RAILS AGAINST THE GREEN CORNER POST AND CENTER CORNER POST ON
THE PLAY SET.
2: LEVEL EACH TOP BRIDGE RAIL AND ATTACH THEM TO THE CORNER POSTS WITH 5/16" X 3-1/2"
LAG SCREWS AND 5/16" WASHERS.
3: MAKE THE BOTTOM OF EACH LOWER BRIDGE RAIL 16" FROM THE TOP OF THE TOP BRIDGE RAIL.
4: ATTACH EACH LOWER BRIDGE RAIL TO THE CORNER POSTS WITH 5/16" X 3-1/2" LAG SCREWS
AND 5/16" WASHERS.
5: ATTACH 5/4 X 3 X 28-1/4" PANEL SLAT TO ROPE LADDER SUPPORT AND FRONT FACE BOARD,
NEXT TO THE BRIDGE RAIL WITH 2" WOOD SCREWS.
STEP 14: BRIDGE RAILS TO PLAY SET
TOP BRIDGE RAIL
BOTTOM BRIDGE RAIL
5/16" X 3-1/2" LAG SCREWS
POSTS ON EACH SIDE WITH
FOR CLARITY.
REMOVED FROM VIEW
AND 5/16" WASHERS
ATTACH TOP AND LOWER
BRIDGE RAILS TO CORNER
NOTE: SOME BOARDS
ATTACH
5/4 X 3 X 28-1/4"
PANEL SLAT
WITH 2" WOOD SCREWS
16"
59"
