Gorilla Treasure Trove II User Manual

EACH VERTICAL TARP SUPPORT SHOULD BE FLUSH TO THE BOTTOM OF THE TOP PANEL BOARD. CENTER
EACH VERTICAL TARP SUPPORT WITH THE CENTER OF THE TOP PANEL BOARD. SQUARE EACH VERTICAL TARP
STEP 21: VERTICAL TARP SUPPORTS
SUPPORT TO THE TOP PANEL BOARD.
2: ATTACH THE VERTICAL TARP SUPPORTS TO THE TOP PANEL BOARDS WITH 2-1/2" WOOD SCREWS.
1: PLACE THE 2 X 4 X 33" VERTICAL TARP SUPPORTS ON THE INSIDE OF THE TOP PANEL BOARDS. THE END OF
2 X 4 X 33"
VERTICAL
TARP
SUPPORT
TOP PANEL
BOARD
SCREWS
WOOD
2-1/2"
TOP PANEL
BOARD
139
