Gorilla Treasure Trove II User Manual

WAVE SLIDE
A
SCALE 1 : 12
DETAIL A
#14 X 1-1/4" PAN HEAD SCREWS
**DO NOT OVERTIGHTEN**
STEP 24: ATTACHING WAVE SLIDE
1: PLACE THE SLIDE IN THE OPENING OF THE CLATTER BRIDGE TOWER AS SHOWN WITH THE
LIP OF THE SLIDE RESTING ON TOP OF THE DECK BOARDS.
2: PREDRILL 1/8" HOLES INTO THE DECK BOARDS AT THE SCREW LOCATIONS.
3: ATTACH THE SLIDE TO THE DECK BOARDS WITH FOUR #14 X 1-1/4" PAN HEAD SCREWS
**DO NOT OVERTIGHTEN**
142

Gorilla Treasure Trove II Specifications

General

Brand	Gorilla
Model	Treasure Trove II
Category	Play Sets & Playground Equipment
Language	English
