Grace Cutie - Task 9 - Adjusting the Rails

33
Cutie Frame
Slide the machine to the far left of the frame. Set the rail height so there is about a nger’s
width of space between the take-up rail and the oor of your sewing machine. Then close
the left height levers.
Task 9 - Adjusting the Rails
Instructions
The rails must be adjusted to accommodate the size of your quilting or sewing machine.
Ensure the frame is fully assembled and the machine installed.
1
Open the levers at the base of both side assemblies.
2
3
Height Lever
(x4)
Take-up Rail
Finger’s Width
of Space
