Grace Cutie - Task 2 - Installing the Sides

12
Cutie Frame
Task 2 - Installing the Sides
Right Rear
Corner Brace
Left Rear
Corner Brace
Front Right
Corner Brace
Front Left
Corner Brace
Parts & Tools Needed:
SBHCS
M5 x 8 mm (x16)
Allen Wrench
3 mm
14
17
Instructions
The frame sides support the rails and hold up your fabric. To install the frame sides, take the
following steps:
Right Side Assembly
Left Side Assembly
Bungee Slide (x4)
Slip the four bungee slides onto the mounts on the front left and right corner braces. This
is a convenient place to store the bungee slides when the bungee accessory isn’t in use.
1
Front Left
Corner Brace
Front Right
Corner Brace
Bungee Slide
(x4)
