Grace Cutie - Task 8 - Installing the Rails

26
Cutie Frame
Task 8 - Installing the Rails
Parts & Tools Needed:
Short Front Rail
Long Take-up Rail Short Take-up Rail
Long Front Rail
Instructions
The rails hold your quilt in place while you work. Please take the following steps to assemble and
install the frame rails:
Locate the long and short take-up rails. The take-up rail pieces have two rectangular cut-
outs on one end.
1
Rail Corner Top (x2)Rail Corner Bottom (x2)
Allen Wrench
2.5 mm
14
17
Allen Wrench
2 mm
Hoop Side Rail (X2)
14
17
Long Take-up
Rail
Short Take-up
Rail
SBHCS
M4 X 25 mm (x6)
