Cutie Frame
Slide the long take-up rail over the connector on the short take-up rail so the screw holes
align with the pre-installed set screws.
2
Connector
Long Take-up
Rail
With the 2 mm Allen wrench, tighten the pre-installed set screws in the take-up rail.
3
Note: If you have trouble sliding the parts together, try loosening
the two set screws in the connector with the 2 mm Allen wrench.
Task 8 - Installing the Rails (Continued)
Set Screws
To Next Page
