Graco 482 Series - Accessories; Repair Kit C02023; Repair Kit C02028

310543 19
Accessories
Use Only Genuine Graco Parts
and Accessories
Repair Kit C02023
Table 1 lists the parts that are supplied in the repair kit
for the pistol grip metering valve.
NOTE: This repair kit is used for meter valves
C02021, C02022, C02025, and C02027.
Table 1. Repair Kit: C02023
Quantity
Part
Number Description
1 C02032 Nut, lock, nylon #5–40
1 C20404 Ring, Snap, 5216-50
1 168518 O-Ring, Viton, 5192-6-V
1 168110 O-Ring, Viton, 5194-8-V
1 106555 O-Ring, Viton, 5192-12-V
1 C20314 O-Ring, Viton, 5194-112-V
2 C20317 O-Ring, Viton, 5194-117-V
1 110095 O-Ring, Buna N,
5192-219-N
1 C02033 Quad Ring
1 C20846 Ring, Back-up, 5284-112
1 918482 Needle chuck tool
Repair Kit C02028
Table 2 lists the parts that are supplied in the repair kit
for the automatic metering valve.
NOTE: This repair kit is used for meter valves
C02078.
Table 2. Repair Kit: C02078
Quantity
Part
Number Description
1 C02036 Needle Set, Lapped
1 C02032 Nut, Lock, Nylon, #5–40
1 C20404 Ring, Snap, 5216–50
1 168518 O-Ring, Viton, 5192–6-V
1 C20988 O-Ring, Viton, 5194-8-V
1 106555 O-Ring, Viton, 5192-12-V
1 C20314 O-Ring, Viton, 5194-112-V
2 C20317 O-Ring, Viton, 5194-117-V
1 C20987 O-Ring, Buna N,
5192-125-N
1 157195 O-Ring, Buna N,
5192-223-N
1 C02033 Quad Ring
1 C02073 Quad Ring
1 C20846 Ring, Back–up
