Graco 482 Series User Manual

2 310543
List of Models
The following table provides a summary of the automatic metering valves (AMV) that are described in this manual.
Part No.
Model Description
C02021 482-B Same as C02022 with the addition of a 7/8–18 UNS-2A threaded boss for mounting.
C02022 482-C This is the basic AMV.
C02025 482-E Same as C02022 but with a 1/4” NPT outlet.
C02026 482-HA Same as C02022 with the addition of a handle.
C02027 482-MS Same as C02021 with the addition of a seal fluid cartridge and a screw to plug the
normal 7/16–20 mounting hole. The 7/8–18 UNS-2A threaded boss must be used for
mounting. (The 7/8–18 UNS-2A thread is an uncommonly used external thread).
