Graco 482 Series User Manual

20 310543
Accessories
Use Only Genuine Graco Parts
and Accessories
Fluid Nozzles
These nozzles fit all automatic metering valves
covered in this manual.
Orifice Size
Nozzle
Part No.
Adapter
Part No.
3/64 in.
(1.2 mm)
C17008;
1/8 npt(m)
not required
3/32 x 3/8 in.
(2.4 x 9.5 mm)
C01025;
1/8 npt(m)
not required
1/16 in.
(1.6 mm)
C02048 C17007;
1/8 npt(m)
ORIFICE SIZE
3/64 DIAMETER
3/32 x 3/8
1/16 DIAMETER
C17008 NOZZLE
C01025 NOZZLE
C17007
ADAPTOR
C02048
NOZZLE
NOZZLES WILL FIT ANY MODEL AMV.
1/8” N.P.T.
Needle Installation Tool 918482
Fig. 5
