Parts List - Lo-Boy Sprayers
30 308870G
Replacement Danger and Warning labels, tags and
cards are available at no cost.
62 162485 NIPPLE, 3/8-18 npsm(m) x
3/8 npt(m)
3
64 194178 HOSE, drain
1
65 241718 DEFLECTOR
1
70 110837 SCREW, flng, hex hd,
5/16-18 x 1-1/2 in.
2
71 110838 LOCKNUT, heavy, hex hd,
5/16-18
6
72 101682 SCREW, cap sch
4
73 108842 SCREW, cap sch
4
77 100214 WASHER, lock spring
4
78 114687 CLIP, retainer
1
80 HUB, armature
1
82 114699 WASHER, thrust
1
83 114672 WASHER, thrust
1
85 194118 BRACKET, pump
1
86 110343 SCREW, cap, sch
2
87 240997 CONUDCTOR, ground
1
88 110249 ADAPTER, male elbow, 90°
1
93 108851 WASHER
2
94 241540 PAIL HOOK Repair Kit,
includes 95
1
95 194681 GROMMET, pump
1
96 206994 THROAT SEAL LIQUID; not
shown
1
97 114695 DOWEL PIN
4
98 241322 ROLLER, assembly
4
99 114693 SCREW, cap, sch
2
101 195523 PIN
1
102 240987 PLUG, packless 3/8 in.
1
103
194317 LABEL, warning
1
104
195119 LABEL, warning; not shown
1
Ref Part No. Description Qty
