Graco G-Max 7900 - Parts List - Lo-Boy Sprayers; Models 232632, 232633

Parts List - Lo-Boy Sprayers
308870G 29
Parts List - Lo-Boy Sprayers
Models 232632, 232633
Ref Part No. Description Qty
1 114530 ENGINE
1
2 113084 RIVET, blind
2
3 192014 PLATE, indicator
1
4 241113 CLUTCH, assembly,
includes 4a, 4b, 15, 17, 72,
80
1
4a ARMATURE, clutch, 5 inch
1
4b ROTOR, 5 inch
1
5 193531 CLUTCH HOUSING
1
7 183401 KEY, parallel
1
8 193680 CLAMP
1
9 104008 WASHER, spring lock
12
10 101864 CAPSCREW, socket head,
1/4-20 x 3/4 in.
10
11 239998 CART HANDLE & HOSE
RACK
1
12 193682 CAP, end
2
15 113802 SCREW, flange, hex hd,
3/8-16 x 5/8 in.
1
16 108803 CAPSCREW, sch, 1/4-2 x 1
in.
6
17 105510 LOCKWASHER, spring, 1/4
in.
15
18 241539 GEAR COMBINATION,
include 91 and 92
1
19 241116 PINION ASSEMBLY; Parts
page 24
1
20 241536 DRIVE HOUSING, Parts,
page 24
1
24 241536 COVER, housing, drive, kit
1
25 100018 WASHER, lock, spring
1
26 100644 SCREW, cap
5
28 240917 DISPLACEMENT PUMP,
Parts manual 308798
1
29 194438 TUBE, nylon, split
1
30 241288 ASSEMBLY, tube suction
1
30a
241269 . TUBE, suction, 30 gallon
(120 L) included 30aa - 3ae
1
30aa
198119 .. SWIVEL, tube inlet
1
30ab
176450 .. GUARD, hose
1
30ac
194307 .. HOSE, fluid
1
30ad
101818 .. CLAMP, hose
2
30ae
192633 .. TUBE, suction
1
30b 194180 . HOSE, drain
1
30c
194194 . CLIP, spring
1
30d
162453 . NIPPLE
1
30e
241718 . DEFLECTOR
1
30f
189920 . STRAINER
1
33 240795 HOSE, coupled
1
34 193394 NUT, retaining
1
35 241324 CART FRAME
1
36 194068 LABEL, identification
1
37 183350 WASHER, plain
2
38 110243 RING, retaining
2
39 108795 SCREW, mch, pn hd, 10-32
x 5/16 in.
4
40 191043 SLEEVE
2
41 179811 WHEEL, semi-pneumatic
2
42 101242 RING, retaining
2
43 104811 HUBCAP
2
44 154636 WASHER
2
45 112827 BUTTON, snap
2
47 237686 GROUNDING, CLAMP &
WIRE
1
49 112798 SCREW, hex washer hd,
No. 8 x 3/8 in.
1
52 114984 SCREW, mch, pn hd
2
56 194126 LABEL, warning
1
61 114678 BUSHING, strain relief
1
Ref Part No. Description Qty
