Part No. 124333: Cable Pin Out (M12)
Wire Colors (F
IG. 13)
Part No. 124300: Field Wireable Pin Out
(M12)
Wire Colors (F
IG. 14)
FIG. 12
Item No. Color
1 Brown
2 White
3 Blue
4 Black
FIG. 13
Item No. Color
1 Brown
2 White
3 Blue
4 Black
