Technical Specifications
40 332291P
Technical Specifications
G3 Standard Automatic Lubrication Pump
US Metric
Pump output pressure 5100 psi 35.1 MPa, 351.6 bar
Fill inlet pressure 5000 psi 34.4 MPa, 344.7 bar
Power
100 - 240 VAC
100 - 240 VAC; 0.8 A current, 90 VA Power, 47/63 Hz, Single phase,
inrush/locked rotor, max 40 A (1ms)
12 VDC 9 - 16 VDC; 5A current, 60 W, inrush/locked rotor 12 A
24 VDC 18 - 32 VDC; 2.5 A current, 60 W, inrush/locked rotor 6 A
Outputs - Low Level (Dry Contact)
Contact rating 10 W Maximum
Switch rating 30 VDC Maximum
Switching current 0.5 A Maximum
Carry current 1.2 A Maximum
Fluid
Grease Models Grease NLGI #000 - #2
Oil Models At least 40 cSt oil
Pumps Up to 3
Pump Outlet
1/4-18 NPSF, Mates with 1/4-18 npt male fittings
Reservoir Size
2, 4, 8, 12, 16 Liters
IP Rating IP69K
Ambient Temps -40°F - 158°F -40°C - 70°C
Noise (dBa)
Maximum sound pressure <70dBa
Materials of Construction
Wetted Parts
nylon 6/6 (PA), amorphous polyamide, T5004-060, zinc plated steel, carbon
steel, alloy steel, stainless steel, nitrile rubber (buna-N), bronze, nickel plated
alnico, chemically lubricated acetal, aluminum, PTFE
All trademarks or registered trademarks are the property of their respective owners.
Pump Maximum Weight lb (kg)
Model With follower plate Without follower plate With auto-fill shut off
2L 12.4 (5.6) 11.4 (5.2) N/A
4L 15.3 (6.9) 13.1 (5.9) 17.9 (8.1)
8L 16.8 (7.6) 14.6 (6.6) 19.7 (8.9)
12L 18.4 (8.3) 16.1 (7.3) 21.6 (9.8)
16L 19.9 (9.0) 17.6 (8.0) 23.4 (10.6)
