Graco Husky 2200 - Pump Dimensions; End Flange Model Dimensions

Dimensions
Dimensions Dimensions
Dimensions
End End
End
Flange Flange
Flange
Models, Models,
Models,
Polypropylene Polypropylene
Polypropylene
and and
and
PVDF PVDF
PVDF
Polypropylene Polypropylene
Polypropylene
PVDF PVDF
PVDF
A A
A
25.1in.63.8cm25.2in.64.0cm
B B
B
28.7in.72.9cm28.8in.73.2cm
C C
C
31.7in.80.5cm31.8in.80.8cm
D D
D
3.6in.9.1cm3.6in.9.1cm
E E
E
12.0in.30.5cm11.7in.29.7cm
F F
F
25.6in.65.0cm25.3in.64.3cm
Polypropylene Polypropylene
Polypropylene
PVDF PVDF
PVDF
G G
G
19.8in.50.3cm19.8in.50.3cm
H H
H
7.0in.17.8cm7.0in.17.8cm
J J
J
13.9in.35.3cm13.9in.35.3cm
K K
K
16.3in.41.4cm16.3in.41.4cm
L L
L
8.2in.20.8cm8.2in.20.8cm
18 3A2578E
