Graco Husky 2200 - Technical Data; Pump Specifications Overview; Air Consumption Data; Noise Level Specifications

TechnicalData
Technical Technical
Technical
Data Data
Data
Husky Husky
Husky
2200 2200
2200
Diaphragm Diaphragm
Diaphragm
Pump Pump
Pump
US US
US
Metric Metric
Metric
Maximum󰘱uidworkingpressure
125psi0.86MPa,8.6bar
Airpressureoperatingrange20to125psi0.14to0.86MPa,1.4to8.6bar
Airinletsize
3/4in.npt(f)
Airexhaustsize
1in.npt(f)
Fluidinletandoutletsize(ANSI/DIN
󰘱ange)
2in50mm
Maximumsuctionlift(reduced
ifballsdon’tseatwelldueto
damagedballsorseats,lightweight
balls,orextremespeedofcycling)
Wet:31ft
Dry:16ft
Wet:9.4m
Dry:4.9m
Maximumsizepumpablesolids3/8in.9.5mm
Minimumambientairtemperature
foroperationandstorage.
NOTE: NOTE:
NOTE:
Exposuretoextremelow
temperaturesmayresultindamage
toplasticparts.
32°F0°C
Air Air
Air
consumption consumption
consumption
Standarddiaphragms70scfmat70psi;100gpm
2.0m
3
/minat0.48MPa,4.8
bar,379lpm
Overmoldeddiaphragms75scfmat70psi,100gpm
2.1m
3
/minat0.48MPa,4.8
bar,379lpm
Maximum Maximum
Maximum
air air
air
consumption consumption
consumption
Standarddiaphragms140scfm
4.0m
3
/min
Overmoldeddiaphragms157scfm
4.4m
3
/min
Noise Noise
Noise
(dBa) (dBa)
(dBa)
SoundpowermeasuredperISO-9614–2.Soundpressurewastested3.28ft(1m)fromequipment.
95.2at70psiand50cpm95.2at4.8barand50cpm
SoundPower
101.8at100psiandfull󰘱ow101.8at7.0barandfull󰘱ow
87.3at70psiand50cpm87.3at4.8barand50cpm
SoundPressure
94.7at100psiandfull󰘱ow94.7at7.0barandfull󰘱ow
Fluid Fluid
Fluid
󰘱ow 󰘱ow
󰘱ow
per per
per
cycle cycle
cycle
Standarddiaphragms
1.6gallons6.1liters
Overmoldeddiaphragms
1.3gallons4.9liters
Maximum Maximum
Maximum
free free
free
- -
-
󰘱ow 󰘱ow
󰘱ow
delivery delivery
delivery
Standarddiaphragms
200gpm757lpm
Overmoldeddiaphragms
200gpm757lpm
