Graco Husky 307 - Safety Warnings and Symbols; Warning and Caution Symbols; Equipment Misuse Hazards

2 308553
Table of Contents
Warnings 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation 4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Operation 11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Troubleshooting 12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Maintenance 14. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Service
Replacing the Air Valve 16. . . . . . . . . . . . . . . . . . . . . .
Repairing the Air Valve 18. . . . . . . . . . . . . . . . . . . . . .
Ball Check Valves 21. . . . . . . . . . . . . . . . . . . . . . . . . .
Diaphragm Repair 23. . . . . . . . . . . . . . . . . . . . . . . . . .
Pump Matrix 26. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Additional Diaphragm Pumps 26. . . . . . . . . . . . . . . . . . .
Repair Kit Matrix 27. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Parts 28. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Torque Sequence 32. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Technical Data and Performance Charts 33. . . . . . . . . .
Dimensions 35. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Graco Warranties 36. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Graco Information 36. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Symbols
Warning Symbol
WARNING
This symbol alerts you to the possibility of serious
injury or death if you do not follow the instructions.
Caution Symbol
CAUTION
This symbol alerts you to the possibility of damage to
or destruction of equipment if you do not follow the
instructions.
EQUIPMENT MISUSE HAZARD
Equipment misuse can cause the equipment to rupture or malfunction and result in serious injury.
D This equipment is for professional use only.
D Read all instruction manuals, tags, and labels before operating the equipment.
D Use the equipment only for its intended purpose. If you are not sure, call your Graco distributor.
D Do not alter or modify this equipment. Use only genuine Graco parts and accessories.
D Check equipment daily. Repair or replace worn or damaged parts immediately.
D Do not exceed the maximum working pressure of the lowest rated component in your system.
This equipment has a 100 psi (0.7 MPa, 7 bar) maximum working pressure at 100 psi
(0.7 MPa, 7 bar) maximum incoming air pressure.
D Use fluids and solvents which are compatible with the equipment wetted parts. Refer to the
Technical Data section of all equipment manuals. Read the fluid and solvent manufacturer’s
warnings.
D Do not kink or overbend hoses or use hoses to pull equipment.
D Route hoses away from traffic areas, sharp edges, moving parts, and hot surfaces. Do not
expose Graco hoses to temperatures above 82_ C (180_ F) or below –40_ C (–40_ F).
D Do not lift pressurized equipment.
D Comply with all applicable local, state, and national fire, electrical, and safety regulations.
WARNING
WARNING
INSTRUCTIONS
