Setup
11. Observe the following cautions to avoid pressure
control
damage.
CAUTION
To
avoid damaging the pressure control, follow these
precautions.
1. Allow
the main hose to act as a pulsation damp
-
ener:
Always use nylon spray
hose at least 50 ft.
(15.2 m) long for the main gun;
Never
use a wire
braid
hose; it is too rigid.
2. Never install a ball valve or shutof f device be-
tween
the filter and the 50 ft. (15 m) hose.
3. Do not allow water or water–base material to
freeze
in the pressure control.
CAUTION
Close the black fuel shutoff lever whenever you are
transporting
the sprayer to prevent fuel from
flooding
the
engine.
Keep
the sprayer upright
and level when operating it
and
when transporting it. This prevents crankcase oil
from leaking into the combustion chamber , which
makes
startup very dif
ficult
12. To
use the wheel brake, lift the brake handle (A– bot
-
tom
rear of cart) to engage the brake. Lower the han
-
dle to disengage the break. See Fig. 3. For positive
break
engagement, be sure there is proper tire
pres
-
sure
and that tire wear is not excessive.
13. For how to operate and adjust the various features
of
the Line Lazer
, see pages 12 – 22.
14.
Start the sprayer
. See page 14.
Fig. 3
03586
A
Fueling
WARNING
Gasoline is extremely flammable and explosive un-
der certain conditions. To reduce the risk of a fire or
explosion:
1. Always
shut of
f the engine before refueling.
2.
Refuel in a well–ventilated area.
3. Do not smoke or allow flames or sparks in the
area where the engine is refueled or where the
gasoline
is stored.
4. Do not overfill the tank. Make sure the filler cap
is
securely closed after refueling.
5. Fuel
vapor or spilled fuel can ignite. If any fuel is
spilled
during refueling, make sure the area is dry
before
starting the engine.
1. Fuel specifications. Use automotive gasoline with a
pump octane number of 86 or higher . If the engine
knocks
or pings, use a higher octane fuel.
Unleaded
fuel
minimizes combustion chamber deposits.
2. Gasolines containing alcohol (gasohol). Do not use
gasohol which contains methanol, if the gasohol
does
not contain cosolvents and corrosion inhibitors
for
methanol. Even if it does contain such
additives,
do not use the gasohol if it contains more than 5%
methanol.
NOTE: The HONDA engine warranty does not cover
damage
resulting from the use of gasolines containing al
-
cohol.
See the HONDA engine manual for more informa
-
tion.
3. General.
Do not use oil
and gasoline mixtures or con
-
taminated
gasoline. A
void getting dirt, dust or water
in the fuel tank.
4. Tank capacity: 0.95 gallons (3.6 liter). Leave 1/2 in.
(13
mm) at the top of the tank for gas expansion.
5.
Shut of
f the engine switch (A) before refueling.
6.
After refueling, tighten the fuel tank cap (B) firmly
.
A
B
0009
Fig. 4
