Setup
3A9019A EN 13
Setup
Assemble Your Sprayer
1. Connect airless hose to airless hose
connection (P) on sprayer. Use wrench
to tighten securely.
2. Connect the other end of the hose to the
gun. Use two wrenches to tighten
securely to gun (see image below).
NOTE: It is important to use two wrenches
when connecting the hose to the gun, both
for ease of installation and to ensure a tight
connection.
If hose is already connected, make sure
connections are tight.
3. Assure Spray Tip is properly inserted
into the Spray Tip Guard, and the Spray
Tip Guard assembly is tightened
securely to gun. See Spray Tip
Installation, page 23.
To avoid serious injury from skin injection,
do not put your hand in front of the Spray
Tip when installing or removing the Spray
Tip or Spray Tip Guard.
