Reference
3A9019A EN 33
Quick Reference
Page
10
Name
Description
A Power - ON/OFF Switch Turns sprayer ON and OFF.
B Pressure Control Knob Increases (clockwise) and decreases
(counter-clockwise) fluid pressure in pump, hose, and
spray gun. To select function, align symbol on pressure
control knob with setting indicator.
C Prime/Spray Valve
• In PRIME position directs fluid to Drain Tube.
• In SPRAY position directs pressurized fluid to paint
hose.
• Automatically relieves system pressure in
overpressure situations.
D Spray Tip
• Atomizes fluid being sprayed, forms spray pattern and
controls fluid flow according to hole size.
• Reverse position unclogs plugged Spray Tips
without disassembly.
E PushPrime Button Taps the inlet ball when pushed to loosen it.
F Suction Tube Draws fluid from paint pail into pump.
G Drain Tube (with diffuser) Drains fluid in system during priming and pressure relief.
H Airless Spray Gun Dispenses fluid.
J Spray Tip Guard Reduces risk of fluid injection injury.
K Gun Trigger Lock Prevents accidental triggering of spray gun.
L Gun Fitting Threaded connection for Airless Hose.
M Gun Filter (inside handle) Filters fluid entering spray gun to reduce Spray Tip clogs.
N ProXChange™ Pump Pumps and pressurizes fluid and delivers it to Airless
Hose.
O Inlet Valve Allows paint to flow from paint bucket into the sprayer.
P Airless Hose Connection Threaded connection for airless hose.
Q Airless Hose Transports high-pressure fluid from pump to spray gun.
R InstaClean Filter
• Filters fluid coming out of pump to reduce Spray Tip
clogs and improve finish.
• Self cleans only during pressure relief.
S Pail Hanger For transporting pail by its handle.
T Inlet Screen Prevents debris from entering pump.
U Battery Power source for sprayer.
V Easy Access Door Permits quick access to the pump. Open pump door by
pulling out on the tabs while sliding door up.
X Pump Removal Tool Cut out in the frame provides the tools to quickly remove
the pump packing without additional tools.
Y Outlet Valve Allows paint to flow from the sprayer to the gun.
Z Inlet Valve Removal Tool Cut out in the frame provides the tools to quickly remove
the inlet valve without additional tools.
Power Flush Valve Connects garden hose to Suction Tube for power
flushing water-based fluids.
AA Battery Cover Protects the battery.
AB Ground Wire w/ Clamp Provides means to maintain good ground continuity.
AC Outlet Ground Adapter Provides a means to attach grounding wire clamp to
grounded electrical outlet.
