Spraying
24 3A9019A EN
a. Use Spray Tip to align gasket and
seal in the Spray Tip Guard.
b. Spray Tip must be pushed all the
way into the Spray Tip Guard.
Rotate Spray Tip while pushing
down.
c. Turn the arrow shaped handle on
the Spray Tip forward to the SPRAY
position.
4. Screw Spray Tip Guard assembly onto
the gun and tighten.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Graco Magnum TrueAirless ProX19 and is the answer not in the manual?

Graco Magnum TrueAirless ProX19 Specifications

General IconGeneral
TypeAirless Paint Sprayer
Maximum Tip Size0.019 inch
Maximum Pressure3000 PSI
Flow Rate0.38 GPM
Power SourceElectric
Motor TypeBrushless
Recommended ApplicationsResidential and Commercial
