Parts
312394C 27
Ref Part Description Qty
101 15T679 COVER, front, accumulator,
mild steel, PR70
1
102 01/1449/99 COVER, back, accumulator,
mild steel
1
103 96/0282/98 FASTENER, screw, button
head cap screw, 8-32 x
0.38, stainless steel
6
104 84/1460-1/11 LABEL, accumulator, air
pressure
1
105 82/0053/11 GAUGE, 0-30psi, 2 in., 1/8
npt, back
1
106 82/0052/11 REGULATOR, air, 1/8 npt,
3-30 psig, 10 scfm
1
107 94/0070/96 FITTING, nipple, 1/8 npt x
1.50, brass
1
108 94/0642/96 FITTING, elbow, 1/8 npt,
female, 90deg, brass
2
109 94/0809/96 VALVE, ball, 2w, 1/8 npt,
male, lp, brass
1
110 15T686 LABEL, accumulator, plant
air in
1
111 01/1454/98 FLANGE, pump, accumula-
tor, 1.5, stainless steel
1
112 121307 FITTING, nipple, 1/2 npt x
3.00, male / male, 304
1
113 94/0616/98A FITTING, tee, 1/2 npt,
female, 3000 psi, 316 ss
1
114 94/0360-2/98 VALVE, check, 1/2 npt,
male, fluoroelastomer, stain-
less steel, adj
1
115 94/0348/11 CAP, valve, check, 1/2 1
116 95/0223/02 O-RING
(assembly LC0297 only)
2
95/0223/00 O-RING, fluoroelastomer
(assembly LC0160 only)
2
117 120904 SCREW, socket head cap,
M5 x 0.8 x 18 mm
3
118 15M849 ADAPTER, accumulator 1
119 96/0304-4/98 NUT, hex, lock, 10-24, stain-
less steel
8
120 94/3201/96 FITTING, union, bulkhead,
1/4 tube
1
121 94/0545/98 PLUG, socket head, 1/8npt,
18-8 stainless steel
1
122 01/1453/99 ROD, tie, accumulator, 1.5 4
123 01/1455/98 CYLINDER, accumulator,
1.5, stainless steel
1
124 01/1451/98 TUBE, vent, accumulator,
1.5, stainless steel
1
125 94/0702/96 FITTING, 1/4tube x 1/8 npt,
male, brass
1
126 01/1456/97 CAP, end, cylinder, accumu-
lator, 1.5
1
127 95/0913/02 O-RING, ep, jbh
(assembly LC0297 only)
2
95/0913/00 O-RING, fluoroelastomer,
jbh (assembly LC0160 only)
2
128 95/0605/01 SEAL, u-cup, 1/2 ID x 3/4
OD, NIT
1
129 96/0611-08/98 NUT, jam, 1/2-20, stainless
steel
1
130 96/0556-08/99 WASHER, Sealing, 1/2, mild
steel
1
131 95/0601/02 SEAL, u-cup, 1-3/16 ID x
1-1/2OD, EP
(assembly LC0297 only)
1
95/0601/00 SEAL, u-cup, 1-3/16 ID x
1-1/2 OD, fluoroelastomer
(assembly LC0160 only)
1
132 01/1452/11 STRIP, piston, magnetic,
accumulator, 1.5
1
133 01/1450/70 PISTON, 1.5 in., 1/2-20,
accumulator, seal/mag
1
134 94/0527/96 FITTING, elbow, str, 1/8 npt,
90 deg, brass
1
135 94/0705-1/96 FITTING, elbow, swivel, 1/4
tube x 1/8 npt
3
136 96/0514/98 WASHER, flat, 1/2, 0.53 x
1.06 x 0.097, stainless steel
1
137 94/0463/96 FITTING, bushing, 1/8 npt x
10-32, brass
1
138 82/0171/11 FITTING, elbow, street,
10-32, adjustable, brass
1
139 82/0241/11 VALVE, qck exh, 10-32, mini 1
140 94/0102/96 CONNECTOR,
1/4tubex10-32, brass
1
141 94/0301-1/98 FITTING, elbow, strt, 90,
1/2npt, stainless steel
1
142 94/0568/98 BUSHING, 1/2x1/4npt,
male/female, stainless steel,
6K, 316
1
143 256179 VALVE, assy, on-board tank
refill
1
144 121516 SENSOR, level, accumula-
tor
2
145 121684 CABLE, M12 x M8, 4P,
female/male,
straight/right angle, 2 m
2
146 121686 CABLE, M8 x M8, 4P,
female/male, straight/right
angle, 2 m
1
Ref Part Description Qty
