Parts
312394C 31
† Part not shown.
Ref Part Description Qty
701 01/2218/97 ENCLOSURE, agitator, electric, prmv/f, hd 1
703 01/2219/97 PLATE, adapter, electric agitator, hd, prm 1
704 81/2218-1/11 MOTOR, 50 rpm, 60 in-lb, 120V, 1.2A
(assembly 255246 only)
1
256613 MOTOR, 50 rpm, 60 in-lb, 230V
(assembly 255503 only)
1
705 81/1040/11 MODULE, ac, 2p, 250V, 10a, double pull sin-
gle throw, w/fuse
1
706 81/1040-1/11 MODULE, ac connector, 2P, 250V, 10A, with
bar
1
707 81/1053-1.6/11 FUSE, 5 x 20 mm, 1.6A, time delay 1
708 84/2215-A/11 COUPLING, alignment, 1 in. OD, hub, 3/8 ID 2
709 84/2215-B/11 COUPLING, alignment, 1 in. OD, disk, nylon 1
710 95/0842/11 SEAL, posipak, 3/8ID x 7/8OD, P/fluoroelas-
tomer
1
711 95/0864/00 O-RING, fluoroelastomer, ada 1
712 96/0271/99 FASTENER, button head cap screw, 8-32 x
0.31, mild steel
8
713 96/0817/99 RING, retaining, external, 0.375, mild steel 1
714 120905 NUT, hex, lock M5 x 0.8 3
715 120907 WASHER, plain #10 11
716 120928 SCREW, button head cap screw, M5 x 0.8 x
25 mm
7
717 120930 WASHER, seal, fluoroelastomer 7
718 120960 SCREW, button head cap screw, M5 x 0.8 x
20 mm, stainless steel
4
719 120961 SCREW, button head cap screw, 10-32 x
1.25 in., stainless steel
4
720 121173 BEARING, ball,
3/8 in. ID x 7/8 in. OD x 9/32 in.
2
721 255724 AGITATOR, shaft and blade assy 1
723 15K884 HOUSING, bearing 1
724 15K885 SPACER, agitator standoff 4
725 15K886 DISK, bearing 1
726
†
121599 CORD, power, v-lock, C14/C13, 10A 1
