Graco PR70 - Page 34

Parts
34 312394C
Agitator Shaft, 255724
907
904
903
905
901
902
901
906
905
ti12458a
Ref Part Description Qty
901 01/2230-1/98 PADDLE, agitator, tfm tank, stainless steel 2
902 01/2230-2/98 SUPPORT, mount, paddle, agitator 1
903 96/0097/98 FASTENER, screw, socket head cap, 10-24
x 1.25, stainless steel
2
904 96/0125/98 FASTENER, screw, socket head cap,
10-24 x 0.50, stainless steel
1
905 96/0129/98 WASHER, flat, SAE, #10, stainless steel,
1/2 in. OD, 0.049
4
906 96/0304-4/98 NUT, hex, lock, 10-24, stainless steel 2
907 15R307 SHAFT, agitator, 8L polyethylene tanks 1
