Parts
312394C 41
† Part not shown.
Ref Part Description
Quantity
LC0019, Lid assembly with Relief LC0020, Lid assembly LC0021, Lid assembly, 120 V Agitator LC0022, Lid assembly, 240 V Agitator LC0023, Lid assembly, Agitator, De-gas LC0024, Lid assembly, Agitator, De-gas LC0025, Lid assembly, Agitator, De-gas, Fill Port LC0026, Lid assembly, Agitator, De-gas, Fill Port LC0130, Lid Assembly, Pneumatic Agitator LC0131, Clamp Down Lid, Pneumatic Agitator, De-gas LC0132, Clamp Down Lid, Pneumatic Agitator, Fill Port
1005 15M392 TA N K , m o d ifie d 1 1 1 1 1 1 1 1 1 1 1
1006 95/0518/00 O-RING, fluoroelastomer, JJF 66666666666
1007 96/0282/98 FASTENER, screw, button head cap screw,
8-32 x 0.38, stainless steel
6 6 6 6 6 6 6 6 6 6 6
1008 96/0820/98 CLAMP, over the center, stainless steel 33333333333
1009 96/0176-1/98 NUT, lock, 8-32, nylock, stainless steel 6 6 6 6 6 6 6 6 6 6 6
1010 15M320 LID, 7L, 2 npt, 1 9/16-32 1 1
15M321 LID, 7L, 2 npt, 1 9/16-32, agitator 1 1 1 1 1 1
15M322 LID, 7L, 2 npt, 9/16-32, agitator, fill port 11 1
1011 94/0752-D/97 VALVE, relief, 9/16-32, 5 psi 1 1 1 1 1 1 1 1 1 1 1
1012
† 94/0736/96
VALVE, drain cock, 1/4 npt, male, brass
1
11 1
1013
† 94/0370/98
PLUG, socket head, 1/4 npt, stainless steel
1 1 1 1 1 1 1 1
1014
† 121090
FITTING, 1/4 npt expander
1
1015 255342 MANIFOLD, vacuum tree 1 1 1 1 1 1 1
1016 94/0299/98 FITTING, elbow, str, 1/4 npt, 45, 3K
112223123
1017 255337 AGITATOR, motor assembly, 120V 1 1 1
255338 AGITATOR, motor assembly, 240V 1 1 1
02/1116/50 AGITATOR, assembly, pneumatic, TFM, 0.32 HP, 15:1 1 1 1
1018 95/0849/11 SEAL, posipak, 3/8 ID x 5/8 OD
111111111
1019 96/0733/87 WASHER, 3/8 x 7/8 x 0.062, PTFE 1 1 1 1 1 1 1 1 1
1020 97/2215/98 SPRING, wave, 0.86 x 0.65 x 0.010, stainless steel
111111111
1021 84/0120/98 BEARING, ball, 0.375ID, DS 2 2 2 2 2 2 2 2 2
1022 255339 AGITATOR, blade assembly
111111111
1023 96/0817/99 RING, retaining, external, 0.375, mild steel 2 2 2 2 2 2 2 2 2
1024 01/2212/70 HOUSING, bearing, electric agitator
111111111
1025 96/0005/98 WASHER, lock, #10, stainless steel 3 3 3 3 3 3 3 3 3
1026 96/0125/98 FASTENER, screw, socket head cap, 10-24X0.50,
stainless steel
333333333
1027 84/2215-B/11 COUPLING, alignment, 1 in. OD, disk, nylon 1 1 1 1 1 1 1 1 1
1028 84/2215-A/11 COUPLING, alignment, 1 in. OD, hub, 3/8 ID
111111111
1029 95/0117/00 O-RING, fluoroelastomer, jai 1 1 1
1030 01/1174-3/97 BULKHEAD, 1/4 npt, tank lid, thin, tfm
11 1
1031 96/0056/98 NUT, hex, jam, 3/4-16, stainless steel 1 1 1
1032 94/0300-1/98A FITTING, elbow, STRT, 90, 1/4 npt, male / female
11 1
1033 94/0320-1/99 FITTING, nipple, hex, 1/4npt, 5K, mild steel 1 1 1
1034 94/0900-R2/98 VALVE, ball, 2W, 1/4npt, female, 2000 psi
11 1
1035 87/0220-2/98 PLATE, slinger, tfm, 3/8ID, 5-1/2OD 1 1 1
1036 95/0524/01 GASKET, lid, tfm, nit 11111111111
