On-Board Polyethylene Feed Systems
Figure 20: PE PNEUMATIC AGITATOR View 1 of 3 (Overall View) (P/Ns: 255730)
Figure 21: PE PNEUMATIC AGITATOR View 2 of 3 (Lower View) (P/N 255730)
1 95/0842/11 POSIPAK,3/8IDX7/8OD,STD,P/VIT 7 120928 SCREW,BHCS,M5X0.8X25MM SST
2 95/0864/00 O-RING,VIT,ADA 8 120930 WASHER,SEAL
3
96/0817/99 RING, RET,EXT,0.375,MS>@@@
9 121173 BEARING,BALL,3/8"IDX7/8"ODX9/32"WIDE SLD
4 ****** LID REPRESENTATION (REFERENCE ONLY) 10 255724 AGITATOR,SHAFT AND BLADE ASSY
5 120905 NUT,HEX,LOCK,M5X0.8,SST 11 15K884 HOUSING,BEARING
6 120907 WASHER,FLAT,#10,SST 12 15K886 DISK,SUPPORT
312394B 20 of 71
