Accumulators
Pneumatic Accumulator Assembly
1 01/1449/99 COVER,BACK,MINI,ACCUM,MS 31 94/0545/98 PLUG,SKT HD,1/8NPT,18-8SS
2 84/1460-5/11 LEGEND,START,STOP,TRANS PUMP 32 121307 NIPPLE,1/2NPTX3.00,304SST
3 01/1448/99 COVER,FRONT,MINI ACCUM,MS 33 94/0616/98 TEE,1/2NPT,F,150PSI,304SS
4 96/0282/98 SCREW,BHCS,8-32X0.38,MS,E@@@ 34 94/0348/11 CAP,VALVE,CHECK,1/2
5 84/1460-1/11 LEGEND,ACCUMULATOR,AIR PRESS 35 82/0047/11 PUSHBUTTON,5/8 DIA HEAD,1/8 DIA ROD
6 84/1460-2/11 LEGEND,HIGH LIMIT
*36 95/0913/00
95/0913/02
O-RING,VIT,JBH,>
O-RING,EP,JBH,>
7 96/0360/99 SCREW,SHC,4-40X0.25,MS,E@@@ *37 95/0601/00
95/0601/02
U-CUP,1-3/16IDX1-1/2OD,VIT
U-CUP,1-3/16IDX1-1/2OD,EP
8 96/0270-1/11 KNOB,KNURLED,6-32X0.38,M *38 94/0360-2/98
94/0360-3/98
VALVE,CHECK,1/2NPT,M,VIT,SS,ADJ,50-150PS
VALVE,CHECK,1/2NPT,M,EP,SS,ADJ,50-150PS
9 96/0161/99 WASHER,FLAT,#6,SS,1/2OD,0.06THIC
K
39 96/0726/99 SCREW,SHC,4-40X0.75,MS,E@@@
10 01/2264/97 POINTER,SW,PROX,PRMV/F 40 82/0263-A/11 ACTUATOR,LEVER,ROLLER
11 84/0067/86 DECAL,SCALE,1" TO 6",PR 41 01/1452/11 STRIP,PISTON,MAGNETIC
12 94/0070/96 NIPPLE,1/8NPTX1.50,BRS 42 01/2259-O1/70 MOUNT,PROX SW,ODV,PRMV/F,7/16WIDE
13 94/0525/96 NIPPLE,HEX,1/8NPT,BRS 43 01/2259-R1/70 MOUNT,PROX SW,RET,PRMV/F,7/16WIDE
14 01/1457/97 BLOCK,MANIFOLD,1/8PORT> 44 15M849 ADAPTER,ACCUMLATOR
15 94/0642/96 ELBOW,1/8NPT,F,90DEG,BRS
*45 95/0223/00
95/0223/02
O-RING,VIT,BBC
O-RING,EP,BBC
16 94/0809/96 VALVE,BALL,2W,1/8NPT,M,LP,BRS 46 94/3201/96 UNION,BULKHEAD,1/4TUBE
17 96/0876/99 SCREW,BHCS,8-32X0.50,MS 47 94/0786/96 TEE,1/4TUBE,PRESTOLOCK,BRS
18 96/0176/99 NUT,HEX,8-32,MS 48 94/0667/96 REDUCER,1/4TUBEX5/32TUBE,PRESTOLOCK
19 84/1460-3/11 LEGEND,LOW LIMIT 50 94/0740-A/99 ELBOW,SWVL,1/4TUBEX10-32,FXM,90DEG
20 84/1460-4/11 LEGEND,AIR IN/OUT 56 94/0463/96 BUSHING,1/8NPTX10-32,BRS
21 01/1456/97 CAP,END,CYLINDER,ACCUM,1.5 57 82/0171/11 ELBOW,STREET,10-32,ADJ,BRS
22 01/1455/98 CYLINDER,ACCUM,1.5,SS 58 94/0102/96 CONNECTOR,1/4TUBEX10-32,BRS
23 95/0605/01 U-CUP,1/2IDX3/4OD,NIT 66 SX10/320/011 VALVE,3W,SR,NC,MANUAL ACTUATION>
24 01/1451/98 TUBE,VENT,ACCUM,1.5,SS 67 G0100088 BODY,VALVE,3W,PBSR,NC,10-32,F
25 01/1453/99 ROD,TIE,ACCU,1.5 69 82/0053/11 GAUGE,PRESS,0-30PSI,2",1/8NPT,BACK
26 96/0010/99 NUT,HEX,10-24,MS 70 82/0241/11 VALVE,QCK EXH,10-32,MINI
27 96/0611-08/98 NUT,JAM,1/2-20,SS 71 82/0052/11 REGULATOR,AIR,1/8NPT,3-30PSIG,10SCFM>
28 96/0556-08/99 WASHER,SEALING,1/2,MS 72 82/0395/11 VALVE,PWR,4W,DP,10-32,SIDE PORT
29 01/1450/70 PISTON,1-
1/2",ACCUM,SEAL/MAG,DEL
74 120904 SCREW,SHCS,M5X0.8X18MM,SST
30 01/1454/98 FLANGE,PUMP,ACCUM,1.5,SS
*Items 36, 37, 38 and 45 Depend on which configuration is being run. Descriptions ending in VIT are for
configurations using VITON and Descriptions ending in EP are for configuration using EPDM.
P/N LC0133 RUNS VITON SEALS
P/N LC0134 RUNS EP SEALS
IT IS RECOMMENDED THAT ALL SEALS SHOULD BE REPLACED AT THE SAME TIME, SO THE
HIGHLIGHTED PARTS CAN BE ORDERED AS PART OF SEAL KITS:
- LC0154 FOR VITON
- LC0155 FOR EP
All fittings and hose are called out on the following page with the logic diagram
312394B 51 of 71
