Off-Board Stainless Steel Feed Systems
Stainless Steel Off-Board Lids (CONT’D)
H. J. K.
L. M. N.
Figure 71: Possible Off-Board Lid Assemblies
K ey:
H. 60L Lid Assy w/ Electric Agitator and Vacuum Degas L. 30L Lid Assy w/ Pneumatic Agitator
J. 30L Lid Assy w/ Electric Agitator, Vacuum Degas, & Fill Port M. 60L Lid Assy w/ Pneumatic Agitator
K. 60L Lid Assy w/ Electric Agitator, Vacuum Degas, & Fill Port N. 30L Lid Assy w/ Pneumatic Agitator and Degas
312394B 56 of 71
