Graco PR70 - Operator (Manual) Mode Operation

Off-Board Stainless Steel Feed Systems
Stainless Steel Off-Board Lids (CONT’D)
P. Q. R.
Figure 72: Possible Off-Board Lid Assemblies
K ey:
P. 60L Lid Assy w/ Pneumatic Agitator and Vacuum Degas
Q. 30L Lid Assy w/ Pneumatic Agitator, Vacuum Degas, & Fill Port
R. 60L Lid Assy w/ Pneumatic Agitator, Vacuum Degas, & Fill Port
312394B 57 of 71
