Troubleshooting
3A4702E 29
Sprayer makes sound
but no material is
sprayed when Trigger is
pulled
Sprayer is not primed. Prime the pump. See Startup,
page 14.
Make certain there is only one
FlexLiner in the Cup Support.
Make certain the cup cover is
properly threaded to the Cup
Support. If threads are visible
below the cup cover when tight,
fully remove and reinstall to the
Cup Support so no threads are
visible when tight.
Make certain the cup cover is
tightened to Cup Support. For
proper sprayer operation lid
must seal tightly with the cup.
Make certain the cup assembly
is properly locked on the
sprayer.
Make certain all the air is out of
the FlexLiner and the VacuValve
is properly closed.
Clean VacuValve reservoir and
air hole. See Cleanup, page 22.
Replace VacuValve.
Clean Sprayer. See Cleanup,
page 22.
Outlet valves are not installed
properly. See Cleaning Outlet
Valves, page 26.
Prime Pump/Spray knob is in PRIME
PUMP position.
Turn Prime Pump/Spray knob
forward to SPRAY position.
Spray Tip is not in SPRAY position. Turn Spray Tip to SPRAY
position.
Spray Tip is clogged. See Clear Tip Clogs, page 19.
Debris in paint. Strain the paint. See Sprayer
Setup, page 11
Pump Filter plugged. See Cleanup, page 22.
Speed Control is set too low. Increase speed until unit sprays.
No or low material in material cup. Refill FlexLiner with material and
prime the pump. See Cup
Refills, page 21.
Pump has reached the end of its life. Replace pump assembly.
Diagnostic Light blinks four times
when the Trigger is pulled. Indicates
a locked rotor condition.
Replace pump and/or motor
assembly.
Problem Cause Solution
