Graco Reactor 2 H-30 Repair Parts

ElectricalSchematics
H H
H
- -
-
40, 40,
40,
H H
H
- -
-
50, 50,
50,
H H
H
- -
-
XP3 XP3
XP3
DIN DIN
DIN
Assembly Assembly
Assembly
Schematics Schematics
Schematics
(350–415V) (350–415V)
(350–415V)
SeeSystemDinRailandHarnessModuleKits,page
95,foradditionalpartnumbers.
24R757
To TB31
17G650
120mm
Enclosure
Fan
80mm
Enclosure
Fan
CB11
CB12
CB13
CB14
CB15
HOSE
MOTOR
A HEAT
B HEAT
TRANS
CT01
POWER
SUPPLY
F12 F11
TB03
TB02
TB01
To HCM
To HCM
24R735
BLU
BRN
BLK
1
1
3
2
24R736
Disconnect
ti26610a
2
16U530
1
Torqueto6–8in-lb(0.7–0.9N•m).
2
Torqueto23–26in-lb(2.6–2.9N•m).
3
Torqueto3–5in-lb(0.3–0.6N•m).
104 334946H
