Graco Reactor H-40 Series Repair And Parts

Motor Control Diagnostic Codes
312063Z 11
Motor Control Diagnostic Codes
Motor control diagnostic codes E21 through E27 appear
on pressure display.
There are two types of motor control codes: alarms and
warnings. Alarms take priority over warnings.
Alarms
Alarms turn off Reactor. Turn main power OFF
then ON to clear.
NOTE: Alarms can also be cleared, except for code 23,
by pressing .
Warnings
Reactor will continue to run. Press to clear. A
warning will not recur for a predetermined amount of
time (varies for different warnings), or until main power
is turned OFF then ON .
E21: No component A
transducer
1. Check transducer A connection at J3 on motor
control board, F
IG. 5, page 32, and clean contacts.
2. Reverse A and B transducer connections. If error
moves to transducer B (E22), replace transducer A,
Transducers, page 33. If error does not move,
replace motor control board, Motor Control Board,
page 31.
E22: No component B
transducer
1. Check transducer B connection at J8 on motor
control board, F
IG. 5, page 32, and clean contacts.
2. Reverse A and B transducer connections. If error
moves to transducer A (E21), replace transducer B,
Transducers, page 33. If error does not move,
replace motor control board, Motor Control Board,
page 31.
E23: High fluid pressure
1. Relieve pressure. Verify low pressure with analog
gauges. Turn main power OFF then ON
. If error persists, do checks below.
2. If pressure imbalance is set to Warning instead of
Alarm (see page 31), an E23 will occur. See E24:
Pressure imbalance for causes and checks.
E24: Pressure imbalance
NOTE: Upon initial start-up this diagnostic code will not
cause an alarm for 2 minutes.
NOTE: If the pressure difference between components
A and B exceeds 500 psi (3.5 MPa, 35 bar), an E24 will
occur. This default value is adjustable; see the operation
manual.
Code Code Name Alarm (A) or
Warning (W)
Corrective
Action
page
21 No transducer
(component A)
A
11
22 No transducer
(component B)
A
11
23 High fluid pressure A
11
24 Pressure imbalance A/W (to
select, see
page 31)
11
27 High motor temperature A
13
30 Momentary loss of
communication
A
14
31 Pumpline reversing switch
failure/high cycle rate
A
14
99 Loss of communication A
14
