Technical Specifications
72 312063Z
Technical Specifications
Reactor H-25, H-40, H-50, H-XP2, and H-XP3
US Metric
Fluid Circulation Ports 1/4 npsm(m), with plastic
tubing, 250 psi maximum
1/4 npsm(m), with plastic
tubing, 1.75 MPa, 17.5 bar
Maximum Fluid Temperature 190 °F 88 °C
Hydraulic reservoir capacity 3.5 gal.
13.6 liters
Amperage Requirement See Models, page 3.
Heater Power
(A and B heaters total, no hose)
See Models, page 3.
Recommended hydraulic fluid Citgo A/W Hydraulic Oil, ISO Grade 46
Sound power, per ISO 9614-2 90.2 dB(A)
Sound pressure, 1 m from equipment 82.6 dB(A)
Wetted Parts Aluminum, stainless steel, zinc-plated carbon steel, brass,
carbide, chrome, fluoroelastomer, PTFE, ultra-high
molecular weight polyethylene, chemically resistant o-rings
Maximum fluid working pressure
Models H-25 and H-40 2000 psi 13.8 MPa, 138 bar
Model H-50 1 phase 1700 psi 11.7 MPa, 11.7 bar
Model H-50 3 phase 2000 psi 13.8 MPa, 138 bar
Models H-XP2 and H-XP3 3500 psi 24.1 MPa, 241 bar
Fluid:Oil pressure ratio
Models H-25 and H-40 1.91:1
Model H-50 1.64:1
Models H-XP2 and H-XP3 2.79:1
Fluid inlets
Component A (ISO)
1/2 npt(f), 250 psi 1.75 MPa, 17.5 bar
Component B (RES)
3/4 npt(f), 250 psi
1.75 MPa, 17.5 bar
Fluid outlets
Component A (ISO) -8 (1/2 in.) JIC, with -5 (5/16 in.) JIC adapter
Component B (RES) -10 (5/8 in.) JIC, with -6 (3/8 in.) JIC adapter
Maximum Output (10 weight oil at ambient temperature)
Model H-25 22 lb/min 10 kg/min, 60 Hz
Model H-XP2
1.5 gpm 5.7 liter/min, 60 Hz
Model H-50
52 lb/min 24 kg/min, 60 Hz
Model H-40
45 lb/min 20 kg/min, 60 Hz
Model H-XP3
2.8 gpm 10.6 liter/min, 60 Hz
Output per Cycle (A and B)
Models H-25 and H-40 0.063 gal. 0.23 liter
Model H-50
0.073 gal. 0.28 liter
Models H-XP2 and H-XP3
0.042 gal. 0.16 liter
Line Voltage Requirement
230V 1 phase and 230V 3 phase units
195-264 Vac 50/60 Hz
400V 3 phase units
338-457 Vac 50/60 Hz
