Technical Data
312062A 37
Technical Data
All other brand names or marks are used for identification purposes and are trademarks of their respective owners.
Category Data
Maximum Fluid Working Pressure Models H-25 and H-40: 2000 psi (13.8 MPa, 138 bar)
Models H-XP2 and H-XP3: 3500 psi (24.1 MPa, 241 bar)
Fluid:Oil Pressure Ratio Models H-25 and H-40: 1.91:1
Models H-XP2 and H-XP3: 2.79:1
Fluid Inlets Component A (ISO): 1/2 npt(f), 250 psi (1.75 MPa, 17.5 bar) maximum
Component B (RES): 3/4 npt(f), 250 psi (1.75 MPa, 17.5 bar) maximum
Fluid Outlets Component A (ISO): #8 JIC (3/4-16 unf), with #5 JIC adapter
Component B (RES): #10 JIC (7/8-14 unf), with #6 JIC adapter
Fluid Circulation Ports 1/4 npsm(m), with plastic tubing, 250 psi (1.75 MPa, 17.5 bar) maximum
Maximum Fluid Temperature 190°F (88°C)
Maximum Output (10 weight oil at
ambient temperature)
Model H-25: 22 lb/min (10 kg/min) (60 Hz)
Model H-XP2: 1.5 gpm (5.7 liter/min) (60 Hz)
Model H-40: 45 lb/min (20 kg/min) (60 Hz)
Model H-XP3: 2.8 gpm (10.6 liter/min) (60 Hz)
Output per Cycle (A and B) Models H-25 and H-40: 0.063 gal. (0.23 liter)
Models H-XP2 and H-XP3: 0.042 gal. (0.16 liter)
Line Voltage Requirement 230V 1 phase and 230V 3 phase units: 195-264 Vac, 50/60 Hz
380V 3 phase units: 338-457 Vac, 50/60 Hz
Amperage Requirement See Models, page 3.
Heater Power
(A and B heaters total, no hose)
See Models, page 3.
Hydraulic reservoir capacity 3.5 gal. (13.6 liters)
Recommended hydraulic fluid Citgo A/W Hydraulic Oil, ISO Grade 46
Sound power, per ISO 9614-2 90.2 dB(A)
Sound pressure, 1 m from equipment 82.6 dB(A)
Weight Units with 8.0 kW Heaters: 570 lb (259 kg)
Units with 12.0 kW Heaters: 597 lb (271 kg)
Units with 15.3 kW Heaters: 597 lb (271 kg)
Units with 20.4 kW Heaters: 597 lb (271 kg)
Wetted Parts Aluminum, stainless steel, zinc-plated carbon steel, brass, carbide, chrome,
fluoroelastomer, PTFE, ultra-high molecular weight polyethylene, chemically
resistant o-rings
