Graco Reactor H-40 Series User Manual

Models
312062A 3
Models
H-25 SERIES
H-40 SERIES
H-XP2 SERIES
H-XP3 SERIES
* Full load amps with all devices operating at maximum capabilities. Fuse requirements at various flow rates and mix
chamber sizes may be less.
** Total system watts, based on maximum hose length for each unit:
• Parts 255400 through 255408, 310 ft (94.6 m) maximum heated hose length, including whip hose.
• Parts 253400 through 253408, 410 ft (125 m) maximum heated hose length, including whip hose
Part,
Series
Full Load
Peak
Amps* Per
Phase
Voltage
(phase)
System
Watts**
Primary
Heater
Watts
Max Flow
Rate
lb/min
(kg/min)
Approximate
Output per
Cycle (A+B)
gal. (liter)
Hydraulic
Pressure
Ratio
Maximum Fluid
Working
Pressure
psi (MPa, bar)
255400, A
69
230V (1) 15,960 8,000 22 (10) 0.063 (0.24) 1.91:1 2000 (13.8, 138)
255401, A
46
230V (3) 15,960 8,000 22 (10) 0.063 (0.24) 1.91:1 2000 (13.8, 138)
255402, A
35
380V (3) 15,960 8,000 22 (10) 0.063 (0.24) 1.91:1 2000 (13.8, 138)
255406, A
100
230V (1) 23,260 15,300 22 (10) 0.063 (0.24) 1.91:1 2000 (13.8, 138)
255407, A
59
230V (3) 23,260 15,300 22 (10) 0.063 (0.24) 1.91:1 2000 (13.8, 138)
255408, A
35
380V (3) 23,260 15,300 22 (10) 0.063 (0.24) 1.91:1 2000 (13.8, 138)
Part,
Series
Full Load
Peak
Amps* Per
Phase
Voltage
(phase)
System
Watts**
Primary
Heater
Watts
Max Flow
Rate
lb/min
(kg/min)
Approximate
Output per
Cycle (A+B)
gal. (liter)
Hydraulic
Pressure
Ratio
Maximum Fluid
Working
Pressure
psi (MPa, bar)
253400, A
100
230V (1) 23,100 12,000 45 (20) 0.063 (0.24) 1.91:1 2000 (13.8, 138)
253401, A
65
230V (3) 26,600 15,300 45 (20) 0.063 (0.24) 1.91:1 2000 (13.8, 138)
253402, A
47
380V (3) 26,600 15,300 45 (20) 0.063 (0.24) 1.91:1 2000 (13.8, 138)
253407, A
75
230V (3) 31,700 20,400 45 (20) 0.063 (0.24) 1.91:1 2000 (13.8, 138)
253408, A
52
380V (3) 31,700 20,400 45 (20) 0.063 (0.24) 1.91:1 2000 (13.8, 138)
Part,
Series
Full Load
Peak
Amps* Per
Phase
Voltage
(phase)
System
Watts**
Primary
Heater
Watts
Max Flow
Rate
lb/min
(kg/min)
Approximate
Output per
Cycle (A+B)
gal. (liter)
Hydraulic
Pressure
Ratio
Maximum Fluid
Working
Pressure
psi (MPa, bar)
255403, A
100
230V (1) 23,260 15,300 1.5 (5.7) 0.042 (0.16) 2.79:1 3500 (24.1, 241)
255404, A
54
230V (3) 23,260 15,300 1.5 (5.7) 0.042 (0.16) 2.79:1 3500 (24.1, 241)
255405, A
35
380V (3) 23,260 15,300 1.5 (5.7) 0.042 (0.16) 2.79:1 3500 (24.1, 241)
Part,
Series
Full Load
Peak
Amps* Per
Phase
Voltage
(phase)
System
Watts**
Primary
Heater
Watts
Max Flow
Rate
lb/min
(kg/min)
Approximate
Output per
Cycle (A+B)
gal. (liter)
Hydraulic
Pressure
Ratio
Maximum Fluid
Working
Pressure
psi (MPa, bar)
253404, A
75
230V (3) 31,700 20,400 2.8 (10.6) 0.042 (0.16) 2.79:1 3500 (24.1, 241)
253405, A
52
380V (3) 31,700 20,400 2.8 (10.6) 0.042 (0.16) 2.79:1 3500 (24.1, 241)

Graco Reactor H-40 Series Specifications

General

Brand	Graco
Model	Reactor H-40 Series
Category	Paint Sprayer
Language	English
