Graco XP70 Instruction & Parts Manual

Models
3A0420H 11
Models
Cart-Mounted XP70 Sprayers
All XP70 sprayers include static mixers, 3/8 x 25 ft hose, clean up mixer, 1/4 x 10 ft (x m) whip hose, and XTR 7 spray
gun with a 519 tip. See Accessories and Kits on page 52 for a list of all optional accessories.
Bare Proportioning Pump Packages
All pump packages use a NXT Air Motor N65DN0.
The pump size is marked on the pump cylinders.
XP70 sprayers are approved for use in hazardous
locations only if the base model, all accessories, all
kits, and all wiring meet local, state, and national
codes.
Sprayer
Volume
Mix
Ratio
Pump
Package
7 Gallon
Hoppers
Maximum Fluid
Working Pressure
psi (MPa, bar)
Maximum Air
Working Pressure
psi (MPa, bar)
Fluid/Air
Pressure Ratio
571101 1:1 571100 7250 (50, 500) 95 (0.6, 6.5)
76:1
571102 1:1 571100
✔
7250 (50, 500) 95 (0.6, 6.5)
571151 1.5:1 571150 7250 (50, 500) 80 (0.5, 5.5)
91:1
571152 1.5:1 571150
✔
7250 (50, 500) 80 (0.5, 5.5)
571201 2:1 571200 7250 (50, 500) 95 (0.6, 6.5)
76:1
571202 2:1 571200
✔
7250 (50, 500) 95 (0.6, 6.5)
571251 2.5:1 571250 6500 (45, 448) 100 (0.7, 7)
65:1
571252 2.5:1 571250
✔
6500 (45, 448) 100 (0.7, 7)
571301 3:1 571300 6800 (47, 469) 100 (0.7, 7)
68:1
571302 3:1 571300
✔
6800 (47, 469) 100 (0.7, 7)
571401 4:1 571400 7250 (50, 500) 100 (0.7, 7)
73:1
571402 4:1 571400
✔
7250 (50, 500) 100 (0.7, 7)
Pump
Package
A Side
Pump
B Side
Pump
Volume
Mix
Ratio
Combined
Fluid
Output
cc/cycle
NXT6500
Fluid/Air
Ratio:1
Fluid Flow
at 40 cpm
gpm (lpm)
Maximum Fluid
Working Pressure
psi (MPa, bar)
Maximum Air
Working Pressure
psi (MPa, bar)
571100 L085C0 L085C0 1:1 173 76 1.8 (6.8) 7250 (50, 500) 95 (0.6, 6.5)
571150 L085C0 L058C0 1.5:1 144 91 1.5 (5.6) 7250 (50, 500) 80 (0.5, 5.5)
571200 L115C0 L058C0 2:1 174 76 1.8 (6.8) 7250 (50, 500) 95 (0.6, 6.5)
571250 L14AC0 L058C0 2.5:1 203 65 2.1 (7.9) 6500 (45, 448) 100 (0.7, 7)
571300 L14AC0 L048C0 3:1 193 68 2.0 (7.5) 6500 (45, 448) 100 (0.7, 7)
571400 L14AC0 L036C0 4:1 181 73 1.9 (7.1) 7250 (50, 500) 100 (0.7, 7)

Graco XP70 Specifications

General

Fluid Output	2.0 gpm (7.6 lpm)
Fluid Delivery	2.0 gpm (7.6 lpm)
Maximum Fluid Working Pressure	7250 psi (500 bar)
Maximum Air Input Pressure	100 psi (7 bar)
Fluid Outlet Size	3/8 in npsm(m)
Wetted Parts	Stainless Steel, PTFE, UHMWPE
Maximum Pressure	7250 psi (500 bar, 50 MPa)
Hose Length	50 ft
