Graco XP70 Instructions

Instructions-Parts
XP
™
and XP-h
™
Proportioners
Mechanically linked fixed ratio plural-component system used for proportioning, mixing,
and spraying two component coatings. For professional use only.
See page 11 for maximum working pressure and model
information.
Important Safety Instructions
Read all warnings and instructions in this
manual and in related manuals. Save
these instructions.
r_571100_3A0420A_1a-2
XP70
™
system shown with hoppers and optional
solvent flush pump and heaters.
3A0420V
EN

Graco XP70 Specifications

General

Fluid Output	2.0 gpm (7.6 lpm)
Fluid Delivery	2.0 gpm (7.6 lpm)
Maximum Fluid Working Pressure	7250 psi (500 bar)
Maximum Air Input Pressure	100 psi (7 bar)
Fluid Outlet Size	3/8 in npsm(m)
Wetted Parts	Stainless Steel, PTFE, UHMWPE
Maximum Pressure	7250 psi (500 bar, 50 MPa)
Hose Length	50 ft
