Graco XP70 Instructions

Parts
56 3A0420V
Bare Proportioning Pump Package
1
Torque together to 50-60 ft-lb (68-81 N•m).
Torque to 145-155 ft-lb (196-210 N•m).
Apply blue thread sealant.
Insert lanyard from locking pin onto pumps (17, 18) as shown.
Do not apply lubricant.
Torque to 70-80 ft-lb (95-108 N•m).
Apply lithium grease to mating tapered surfaces.
1
2
3
4
5
6
7
r_258914_3A0420A_2a
r_258914_3A0420A_3a
101
102
103
104
109
108
107
110
123
121
101
134
131
116
116
112
130
130
138
122
128
106
105
117
117 or 118
108
137
136
139
129
135
122
120
119
1
1
1
1
2 3
4
113
5
3
133
140
3 6
111
7
7
Model 571100 shown

Graco XP70 Specifications

General

Fluid Output	2.0 gpm (7.6 lpm)
Fluid Delivery	2.0 gpm (7.6 lpm)
Maximum Fluid Working Pressure	7250 psi (500 bar)
Maximum Air Input Pressure	100 psi (7 bar)
Fluid Outlet Size	3/8 in npsm(m)
Wetted Parts	Stainless Steel, PTFE, UHMWPE
Maximum Pressure	7250 psi (500 bar, 50 MPa)
Hose Length	50 ft
