Parts
3A0420V 55
Parts Varying By Model - XPh-70 Systems
Replacement Danger and Warning labels, tags, and
cards are available at no cost.
Ref Part Description
Quantity by System
284106
284107
284206
284207
284255
284257
284306
284307
284406
284407
4 284103 PUMP PACKAGE, fixed Ratio 1:1
11
284203 PUMP PACKAGE, fixed Ratio 2:1
11
284253 PUMP PACKAGE, fixed Ratio 2.5:1
11
284303 PUMP PACKAGE, fixed Ratio 3:1
11
284403 PUMP PACKAGE, fixed Ratio 4:1
11
5 100133 Washer, lock, 3/8
10 10 10 10 10 10 10 10 10 10
18 100131 NUT; full hex
6666666666
20 512519 MIXER, 1/2-12 element
3333333333
22 158491 FITTING, nipple
4646464646
23 15M987 FITTING, elbow, 60°
2424242424
25 H73825 HOSE, coupled, 7250 psi, .375 ID, 25 ft
1111111111
26 15B729 COUPLING
1111111111
27 262478 HOUSING, mixer
3333333333
28 248927 KIT, mixer element, 25 pack
1111111111
29 150287 COUPLING
1111111111
30 H72510 HOSE, coupled, 7250 psi, .25 ID, 10 ft
1111111111
31 XTR704 GUN, XTR7
1111111111
32 162024 COUPLING
2222222222
35 262806 MANIFOLD, recirculation, 1/2 valves
1111111111
36 262807 MANIFOLD, mix, 1/2 valves
1111111111
41 158683 FITTING, elbow, 90 degree
2424242424
48 101566 NUT, lock
2222222222
51 124450 CLAMP, spring, constant-tension
2222222222
52 124293 BOLT, u-bolt, 3/8-16, 1.00 dia
1111111111
55 24E872 BRACKET, hopper
2222222222
56 262479 HOPPER, blue
1111111111
57 262480 HOPPER, green
1111111111
60 H52506 HOSE, coupled, 5600 psi, .25 ID, 6 ft
2222222222
61 16D376 FITTING, swivel, 1-1/4, with plug
2222222222
62 111192 SCREW, cap flange head
4444444444
65 262482 STRAINER, hopper, 7 gallon
2222222222
66 15T468 LABEL, warning
2222222222
68 114958 STRAP, tie
10 16 10 16 10 16 10 16 10 16
90 16J688 PLUG, hole, gauge
1 1 1 1 1
