Graco XP70 Instructions

Related Manuals
3A0420V 3
Related Manuals
Manuals are available at www.graco.com. Component
manuals in English:
Manual Description
312145
XTR
™
5 and XTR
™
7 Spray Guns
Instructions-Parts
Pump Package Components
307158
Viscount
®
II Hydraulic Motor Instruc-
tions-Parts
311238
NXT
®
Air Motor Instructions-Parts
311762
Xtreme
®
Displacement Pumps
Instructions-Parts
334914
GH
™
Power Pack Instructions-Parts
Hopper Kits
312747
20 Gallon Double Wall Hopper Kit
Instructions-Parts
406860
7 Gallon Hopper Installation Kit Instruc-
tions-Parts
Heating
309524
Viscon
®
HP Heater Instructions-Parts
309525 Heated Hose Kit, Instructions-Parts
313259 Hopper or Hose Heat Circulation Kit
406861
Viscon HP Heater Adapter Kit, Instruc-
tions-Parts
Solvent Flush
310863 Feed and Solvent Flush Kits
312794
Merkur
®
Pump Assembly
Instructions-Parts
Accessories and Kits
309852
Polyurethane Circulation and Return
Tube Kits, Instructions-Parts
311486
DataTrak
™
Conversion Kit, Instruc-
tions-Parts
312769
Feed Pump and Agitator Kits
Instructions-Parts
339361
High Pressure Hose and Accessories
Brochure
3A0421 Ratio Check Kit, Instructions-Parts
3A0590
Mix Manifold, Quickset Mix Manifold
Instructions-Parts
3A2573
Gun Splitter Valve with Independent
Flush, Instructions-Parts
406739 Desiccant Kit Instructions-Parts

Graco XP70 Specifications

General

Fluid Output	2.0 gpm (7.6 lpm)
Fluid Delivery	2.0 gpm (7.6 lpm)
Maximum Fluid Working Pressure	7250 psi (500 bar)
Maximum Air Input Pressure	100 psi (7 bar)
Fluid Outlet Size	3/8 in npsm(m)
Wetted Parts	Stainless Steel, PTFE, UHMWPE
Maximum Pressure	7250 psi (500 bar, 50 MPa)
Hose Length	50 ft
