Models
14 3A0420V
Bare Proportioning Pump Packages
Packages include motor, pump lowers, and all connec-
tion hardware.
NOTE: All pump packages are Ex rated except for the
XP-h pump packages (284xxx):
Hydraulically powered pump packages (XP-h) are not
available as complete systems. Refer to manual 307158
for hydraulic application information.
Pump sizes are marked on the pump cylinder; sizes are
nominal. See technical data in manual 311762 for actual
displacement.
Building systems with bare proportioning pump
packages:
• Over Pressure Protection must be used, see
page 9. See chart on page 42 to identify the over
pressure relief valves to use with your system.
• All components must meet or exceed maximum
working pressures.
Type
Pump
Package
A Side
Pump
B Side
Pump
Volume
Mix
Ratio
Combined
Fluid
Output
cc/cycle
Pressure
Ratio
Fluid Flow
at 40 cpm
gpm (lpm)
Maximum Fluid
Working
Pressure
psi (MPa, bar)
Maximum Air/
Hydraulic Oil
Working Pressure
psi (MPa, bar)
Ex
Rated
Over
Pressure
Relief
Valve To
Use
XP35 with
NXT 3400
Air Motor
281100 L090C0 L090C0 1.0:1 180 38:1 1.9 (7.2) 3500 (24, 241) 95 (0.65, 6.5)
Purple
281200 L115C0 L058C0 2.0:1 173 40:1 1.8 (6.8) 3500 (24, 241) 85 (0.59, 5.9)
262803 L14AC0 L058C0 2.5:1 202 34:1 2.1 (7.9 3500 (24, 241) 100 (0.7, 7)
281300 L14AC0 L048C0 3.0:1 192 36:1 2.0 (7.6) 3400 (23, 234) 95 (0.65, 6.5)
281400 L14AC0 L036C0 4.0:1 180 38:1 1.9 (7.2) 3500 (24, 241) 90 (0.62, 6.2)
XP50 with
NXT 6500
Air Motor
282100 L14AC0 L14AC0 1.0:1 288 45:1 3.1 (11.7) 4500 (31, 310) 100 (0.7, 7)
Gold
282150 L14AC0 L097C0 1.5:1 240 55:1 2.6 (9.8) 5000 (34, 345) 90 (0.62, 6.2)
282200 L18AC0 L090C0 2.0:1 270 48:1 2.9 (11.0) 4800 (33, 331) 100 (0.7, 7)
282250 L18AC0 L072C0 2.5:1 252 52:1 2.7 (10.2) 5000 (34, 345) 95 (0.65, 6.5)
282300 L22AC0 L072C0 3.0:1 288 45:1 3.1 (11.7) 4500 (31, 310) 100 (0.7, 7)
282330 L18AC0 L054C0 3.3:1 234 56:1 2.5 (9.5) 5000 (34, 345) 95 (0.65, 6.5)
282400 L22AC0 L054C0 4.0:1 270 48:1 2.9 (11.0) 4800 (33, 331) 100 (0.7, 7)
XP70 with
NXT 6500
Air Motor
571100 L090C0 L090C0 1.0:1 180 72:1 1.9 (7.2) 7250 (50, 500) 100 (0.7, 7)
Silver
571150 L085C0 L058C0 1.5:1 144 91:1 1.5 (5.6) 7250 (50, 500) 80 (0.55, 5.5)
571200 L115C0 L058C0 2.0:1 174 76:1 1.8 (6.8) 7250 (50, 500) 95 (0.65, 6.5)
571250 L14AC0 L058C0 2.5:1 203 65:1 2.1 (7.9) 6500 (45, 448) 100 (0.7, 7)
571300 L14AC0 L048C0 3.0:1 193 68:1 2.0 (7.5) 6500 (45, 448) 100 (0.7, 7)
571400 L14AC0 L036C0 4.0:1 181 73:1 1.9 (7.2) 7250 (50, 500) 100 (0.7, 7)
XP-h with
Viscount II
Hydraulic Motor
284101 L22AC0 L22AC0
1.0:1
435 1.75:1 4.6 (17.4) 3150 (22, 217) 1800 (12, 124) Purple
284102 L14AC0 L14AC0 293 2.63:1 3.1 (11.7) 4700 (32, 324) 1800 (12, 124) Gold
284103 L090C0 L090C0 180 4.21:1 1.9 (7.2) 7150 (49, 493) 1700 (12, 117) Silver
284201 L29AC0 L14AC0
2.0:1
435 1.75:1 4.6 (17.4) 3150 (22, 217) 1800 (12, 124) Purple
284202 L18AC0 L090C0 274 2.81:1 2.9 (11.0) 5050 (35, 348) 1800 (12, 124) Gold
284203 L115C0 L058C0 170 4.39:1 1.8 (6.8) 7200 (50, 496) 1650 (11, 114) Silver
284251 L29AC0 L115C0
2.5:1
407 1.88:1 4.3 (16.3) 3400 (23, 234) 1800 (12, 124) Purple
284252 L18AC0 L072C0 255 3.02:1 2.7 (10.2) 5000 (34, 345) 1650 (11, 114) Gold
284253 L14AC0 L058C0 199 3.77:1 2.1 (7.9) 6800 (47, 469) 1800 (12, 124) Silver
284301 L29AC0 L097C0
3.0:1
388 1.97:1 4.1 (15.5) 3500 (24, 241) 1800 (12, 124) Purple
284302 L22AC0 L072C0 293 2.63:1 3.1 (11.7) 4700 (32, 324) 1800 (12, 124) Gold
284303 L14AC0 L048C0 189 3.95:1 2.0 (7.6) 7100 (49, 490) 1800 (12, 124) Silver
284401 L29AC0 L072C0
4.0:1
360 2.10:1 3.8 (14.4) 3800 (26, 262) 1800 (12, 124) Purple
284402 L22AC0 L054C0 274 2.80:1 2.9 (11.0) 5000 (34, 345) 1800 (12, 124) Gold
284403 L14AC0 L036C0 180 4.21:1 1.9 (7.2) 7150 (49, 493) 1700 (12, 117) Silver
