Graco XP70 Instructions

Models
3A0420V 13
Typ
eModel
Pump
Package
Volume
Mix
Ratio
7 Gallon
Hoppers
Mix
Manifold Hose Gun
Max Fluid
Working Pressure
psi (MPa, bar)
Max Hydraulic
Oil Working
Pressure
psi (MPa, bar)
Pressure
Ratio
XP-h with Viscount II
Hydraulic Motor
284104 284102 1:01 
Standard
35 ft
(10.7 m)
XTR504
4700 (32, 324) 1800 (12, 124) 1:1
284204 284202 2:01  5050 (35, 348) 1800 (12, 124) 2:1
284254 284252 2.5:1  5000 (34, 345) 1650 (11, 114) 2.5:1
284304 284302 3:01  4700 (32, 324) 1800 (12, 124) 3:1
284404 284402 4:01  5000 (34, 345) 1800 (12, 124) 4:1
284106 284103 1:01 
XTR704
7150 (50, 500) 1700 (12, 117) 1:1
284206 284203 2:01  7200 (50, 496) 1650 (11, 114) 2:1
284256 284253 2.5:1  6800 (47, 469) 1800 (12, 124) 2.5:1
284306 284303 3:01  7100 (49, 490) 1800 (12, 124) 3:1
284406 284403 4:01  7150 (49, 493) 1700 (12, 117) 4:1

Graco XP70 Specifications

General

Fluid Output	2.0 gpm (7.6 lpm)
Fluid Delivery	2.0 gpm (7.6 lpm)
Maximum Fluid Working Pressure	7250 psi (500 bar)
Maximum Air Input Pressure	100 psi (7 bar)
Fluid Outlet Size	3/8 in npsm(m)
Wetted Parts	Stainless Steel, PTFE, UHMWPE
Maximum Pressure	7250 psi (500 bar, 50 MPa)
Hose Length	50 ft
