Graco XP70 Instructions

Parts
54 3A0420V
Parts Varying By Model - XPh-50 Systems
Ref Part Description
Quantity by System
284104 284105 284204 284205 284254 284255 284304 284305 284404 284405
4 284102 PUMP PACKAGE, fixed Ratio 1:1
11
284202 PUMP PACKAGE, fixed Ratio 2:1
11
284252 PUMP PACKAGE, fixed Ratio 2.5:1
11
284302 PUMP PACKAGE, fixed Ratio 3:1
11
284303 PUMP PACKAGE, fixed Ratio 4:1
11
5 100133 Washer, lock, 3/8
10 10 10 10 10 10 10 10 10 10
18 100131 NUT; full hex
6 666666666
20 512519 MIXER, 1/2-12 element
3 333333333
22 158491 FITTING, nipple
4 646464646
23 15M987 FITTING, elbow, 60°
2 424242424
25 H53825 HOSE, coupled, 5600 psi, .375 ID, 25 ft
1 111111111
26 15B729 COUPLING
1 111111111
27 262478 HOUSING, mixer
3 333333333
28 248927 KIT, mixer element, 25 pack
1 111111111
29 150287 COUPLING
1 111111111
30 H52510 HOSE, coupled, 5600 psi, .25 ID, 10 ft
1 111111111
31 XTR504 GUN, XTR5
1 111111111
32 162024 COUPLING
2 222222222
35 262783 MANIFOLD, recirculation, 1/2 valves
1 111111111
36 262807 MANIFOLD, mix, 1/2 valves
1 111111111
41 158683 FITTING, elbow, 90 degree
2 424242424
48 101566 NUT, lock
2 222222222
51 124450 CLAMP, spring, constant-tension
2 222222222
52 124293 BOLT, u-bolt, 3/8-16, 1.00 dia
1 111111111
55 24E872 BRACKET, hopper
2 222222222
56 262479 HOPPER, blue
1 111111111
57 262480 HOPPER, green
1 111111111
60 H52506 HOSE, coupled, 5600 psi, .25 ID, 6 ft
2 222222222
61 16D376 FITTING, swivel, 1-1/4, with plug
2 222222222
62 111192 SCREW, cap flange head
4 444444444
65 262482 STRAINER, hopper, 7 gallon
2 222222222
66 15T468 LABEL, warning
2 222222222
68 114958 STRAP, tie
10 16 10 16 10 16 10 16 10 16
90 16J688 PLUG, hole, gauge
1 1 1 1 1

Graco XP70 Specifications

General

Fluid Output	2.0 gpm (7.6 lpm)
Fluid Delivery	2.0 gpm (7.6 lpm)
Maximum Fluid Working Pressure	7250 psi (500 bar)
Maximum Air Input Pressure	100 psi (7 bar)
Fluid Outlet Size	3/8 in npsm(m)
Wetted Parts	Stainless Steel, PTFE, UHMWPE
Maximum Pressure	7250 psi (500 bar, 50 MPa)
Hose Length	50 ft
