Graco XP70 Instructions

Parts
3A0420V 53
Parts Varying By Model - XP70 Systems
 Replacement Danger and Warning labels, tags, and
cards are available at no cost.
Ref Part Description
Quantity (By System)
571000 571101 571102 571151 571152 571201 571202 571251 571252 571301 571302 571401 571402
4 571100 PUMP PACKAGE, fixed ratio, 1.0:1 1 1
571150 PUMP PACKAGE, fixed ratio, 1.5:1 1 1
571200 PUMP PACKAGE, fixed ratio, 2.0:1 1 1
571250 PUMP PACKAGE, fixed ratio, 2.5:1 1 1
571300 PUMP PACKAGE, fixed ratio, 3.0:1 1 1
571400 PUMP PACKAGE, fixed ratio, 4.0:1 1 1
5 100133WASHER, lock, 3/8 7 711711711711711711
17258983MODULE, air controls, inlet 1111111111111
18100131NUT, full hex 3373737373737
20 512519 MIXER, 1/2-12 element 3 3 3 3 3 3 3 3 3 3 3 3 3
22158491FITTING, nipple 4444444444444
2315M987FITTING, elbow, 60 degree 2222222222222
25 H73825 HOSE, coupled, 7250 psi, 0.375 ID, 25 ft 1 1 1 1 1 1 1 1 1 1 1 1 1
26 15B729 COUPLING 1 1 1 1 1 1 1 1 1 1 1 1 1
27 262478 HOUSING, mixer 3 3 3 3 3 3 3 3 3 3 3 3 3
28 248927 KIT, mixer element, 25 pack 1 1 1 1 1 1 1 1 1 1 1 1 1
29 150287 COUPLING 1 1 1 1 1 1 1 1 1 1 1 1 1
30 H72510 HOSE, coupled, 7250 psi, 0.25 ID, 10 ft 1 1 1 1 1 1 1 1 1 1 1 1 1
31 XTR704 GUN, XTR7 1 1 1 1 1 1 1 1 1 1 1 1 1
32 162024 COUPLING 2 2 2 2 2 2 2 2 2 2 2 2 2
35 262806 MANIFOLD, recirculation, 1/2 valves 1 1 1 1 1 1 1 1 1 1 1 1 1
36 262807 MANIFOLD, mix, 1/2 valves 1 1 1 1 1 1 1 1 1 1 1 1 1
41158683FITTING, elbow, 90 degree 2222222222222
48 101566 NUT, lock 2 2 2 2 2 2 2 2 2 2 2 2 2
51 124450 CLAMP, spring, constant-tension 2 2 2 2 2 2
52 124293 BOLT, u-bolt, 3/8-16, 1.00 dia 1 1 1 1 1 1 1 1 1 1 1 1 1
55 24E872 BRACKET, hopper 2 2 2 2 2 2
56 262479 HOPPER, blue 1 1 1 1 1 1
57 262480 HOPPER, green 1 1 1 1 1 1
60 H52506 HOSE, coupled, 5600 psi, 0.25 ID, 6 ft 2 2 2 2 2 2
H52510 HOSE, coupled, 5600 psi, 0.25 ID, 10 ft 2 2 2 2 2 2 2
61 16D376 FITTING, swivel, 1-1/4, with plug 2 2 2 2 2 2
62 111192 SCREW, cap flange head 4 4 4 4 4 4
64 113498 VALVE, safety, 110 psi 1 1 1 1 1 1 1 1 1 1 1
116643 VALVE, safety, relief, air, 90 psi 1 1
65 262482 STRAINER, hopper, 7 gallon 2 2 2 2 2 2
66 15T468 LABEL, warning 2 2 2 2 2 2
68 114958STRAP, tie 10101010101010101010101010
90 16J688 PLUG, hole, gauge 1 1 1 1 1 1 1 1 1 1 1 1 1

Graco XP70 Specifications

General

Fluid Output	2.0 gpm (7.6 lpm)
Fluid Delivery	2.0 gpm (7.6 lpm)
Maximum Fluid Working Pressure	7250 psi (500 bar)
Maximum Air Input Pressure	100 psi (7 bar)
Fluid Outlet Size	3/8 in npsm(m)
Wetted Parts	Stainless Steel, PTFE, UHMWPE
Maximum Pressure	7250 psi (500 bar, 50 MPa)
Hose Length	50 ft
