Parts
52 3A0420V
Parts Varying By Model - XP50 Quickset Systems
 Replacement Danger and Warning labels, tags, and
cards are available at no cost.
Ref Part Description
Quantity (By System)
283101 283102 283201 283202 283301 283302 283401 283402
4 282100 PUMP PACKAGE, fixed ratio, 1.0:1 1 1
282200 PUMP PACKAGE, fixed ratio, 2.0:1 1 1
282300 PUMP PACKAGE, fixed ratio, 3.0:1 1 1
282400 PUMP PACKAGE, fixed ratio, 4.0:1 1 1
5100133WASHER, lock, 3/8 711711711711
17 258983 MODULE, air controls, inlet 1 1 1 1 1 1 1 1
18 100131 NUT, full hex 3 7 3 7 3 7 3 7
22 158491 FITTING, nipple 4 4 4 4 4 4 4 4
23 15M987 FITTING, elbow, 60 degree 2 2 2 2 2 2 2 2
28 248927 KIT, mixer element, 25 pack 1 1 1 1 1 1 1 1
31 248844 GUN, Flex 1 1 1 1 1 1 1 1
32 162024 COUPLING 1 1 1 1 1 1 1 1
35 262783 MANIFOLD, recirculation, 1/2 valves 1 1 1 1 1 1 1 1
36 24M398 MANIFOLD, Quickset 1 1 1 1 1 1 1 1
41 158683 FITTING, elbow, 90 degree 2 2 2 2 2 2 2 2
51 124450 CLAMP, spring, constant-tension 2 2 2 2
55 24E872 BRACKET, hopper 2 2 2 2
56 262479 HOPPER, blue 1 1 1 1
57 262480 HOPPER, green 1 1 1 1
60 H52506 HOSE, coupled, 5600 psi, 0.25 ID, 6 ft 2 2 2 2
H52510 HOSE, coupled, 5600 psi, 0.25 ID, 10 ft 3 1 3 1 3 1 3 1
61 16D376 FITTING, swivel, 1-1/4, with plug 2 2 2 2
62 111192 SCREW, cap flange head 4 4 4 4
64 113498 VALVE, safety, 110 psi 1 1 1 1 1 1 1 1
65 262482 STRAINER, hopper, 7 gallon 2 2 2 2
66 15T468 LABEL, warning 2 2 2 2
68114958STRAP, tie 1010101010101010
90 16J688 PLUG, hole, gauge 1 1 1 1 1 1 1 1

Graco XP70 Specifications

General

Fluid Output	2.0 gpm (7.6 lpm)
Fluid Delivery	2.0 gpm (7.6 lpm)
Maximum Fluid Working Pressure	7250 psi (500 bar)
Maximum Air Input Pressure	100 psi (7 bar)
Fluid Outlet Size	3/8 in npsm(m)
Wetted Parts	Stainless Steel, PTFE, UHMWPE
Maximum Pressure	7250 psi (500 bar, 50 MPa)
Hose Length	50 ft
